Name: HGHTStop Valves Directional control valvesJeou Gang HG42113223 for hydraulic oil system
Brand: Jeou Gang
Price: 1 USD

Brand Name : Jeou Gang

Model Number : HG-4211-32-23

Place of Origin : Taiwan

MOQ : 1

Price : contact

Payment Terms : TT

Supply Ability : 100unit / month

Delivery Time : 15 days

Contact Now

HG,HT.Stop Valves Directional control valves

MODLE			NOMINAL VAVLE SIZE	MAX. OPERATING PRESSURE kgf/cm²	RATED FLOW l/min
THREADED CONNECTIONS	FLANGED CONNECTIONS	SUB-PLATE MOUNTING	NOMINAL VAVLE SIZE	MAX. OPERATING PRESSURE kgf/cm²	RATED FLOW l/min
HT-4211-10-23	HF-4211-10-23	HG-4211-10-23	3/8”	315	30
HT-4211-15-23	HF-4211-15-23	-	1/2”		60
HT-4211-20-23	HF-4211-20-23	HG-4211-20-23	3/4”		100
HT-4211-25-23	HF-4211-25-23	-	1”		220
HT-4211-32-23	HF-4211-32-23	HG-4211-32-23	1-1/4”		280
-	HF-4211-40-23	-	1-1/2”		500
-	HF-4211-50-23	-	2”		800
